DESCRIPTION

Basic Info.

Model NO.	Q41/11F
Driving Mode	Manual
Nominal Pressure	ANSI CLASS 150-900
Channel	Straight Through Type
Structure	Floating Ball Valve
Type	Floating Ball Valve
Function	Blow-Down Valve
Temperature	Ultralow Temperature
Application	Industrial Usage
Pressure	900lb
Body	A105
Ball	F316
Stem	F316
Seat	PTFE
Transport Package	Wooden
Specification	DN15-DN250
Trademark	yuefeng
Origin	Zhejiang Lishui
HS Code	8481804090
Production Capacity	5000

Product Description

MAIN FEATURES
PRODUCT RANGE
Class 150 from ½'' to 10''
Class 300 from ½'' to 8''
Class 600 from 1/2" to 4"

MATERIALS
BODY: Carbon steel, Stainless steel, Low temperature carbon steel, Duplex, Special Alloys,... Other materials under request
SOFT SEATS : PTFE, RPTFE, PEEK, DEVLON, NYLON,... Other materials under request
METAL SEAT:Tungsten Carbide(TC), Stellited
, Ni60...Other materials under request.
TRIM: A105+EP,304,316, 410, MONEL,... Other materials under request
DESIGN STANDARDS
ASME Standards:
B1.20.1Pipe Threads,General Purpose(Inch)
B16.10Face-to-Face and End-to-End Dimensions of Valves
B16.25Buttwelding Ends
B16.11Forged Fittings, Socket-Welding and Threaded
B16.5Flanged Fittings and Pipe Flanges
B16.47Large Diameter Steel Flanges
API Standards:
6DSpecifications for Pipeline valves
598Valve Inspection and Testing
607Fire test for soft-seated quarter-turn valves
6FASpecification for Fire Test for Valves
MSS Standards:
SP-55Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Visual Method for Evaluation of Surface Irregularities
SP-54Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Radiographic Examination Method
SP-53Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Magnetic Particle Examination Method
Certificates & Test reports

Packing&Shipping
FAQQ:Are you a trading company or a manufacturer?We are a manufacturer with a 13,000 square metre factory.Q:Can you provide assembly drawings?Yes, we will provide the relevant drawings as soon as possible if you need them.Q:How do you guarantee the quality of your products?A: Before the products leave the factory, our quality inspectors will inspect each product before shipment to ensure the pass rate.Q: Can you produce different standard valves according to customers' requirements?A: Yes, please provide specific details, such as model, size, pressure, material and so on.Q:How long is your delivery time?A: Usually 15-30 days, it depends on the order quantity and our storage.

Brand:	Yuefeng
Applicable Media:	Water, Oil, Gas, Nitric Acid, Acetic Acid
Certification:	CE/RoHS/ISO9001-2008
Original	Lishui,Zhejiang Province
Packing:	Plastic Bag, Carton & Plywood Case/According to customers' requirement.
Payment:	T/T, L/C, D/P, Western Union.
Port:	Shenzhen, Customers' Request
Delivery Time:	Within 15days after receiving T/T deposit Payment
Term of Delivery:	EXW/FOB/CNF/CIF, Customers' Request

PRODUCT	SIZE	PRESSURE	POWER	BRAND NAME
DBB BALL VALVE	1/2"-48"	150lb-2500lb	WORM, PNEUMAITC, HYDRAULIC	YFV, OEM
